The Super Dominator 1200 accepts QL120 shank bits and drills most efficiently at air pressures between 100 psi (7 bar) and 435 psi (30 bar). Due to its higher air consumption, it provides increased uphole velocity, particularly when using oversized diameter drill bits.
The Super Dominator 1200 has a one piece top-adaptor with N.R.V. (Non-Return-Valve) fitted for easy inspection and service, with integral finger to reduce maintenance and eliminate shimming which increases service intervals. The Super Dominator 1200 has a robust top-adaptor for extra strength.
Suitable for operation at air pressures of 100 - 435 psi (7 - 30 bar).
Drilling diameters of 311 - 445 mm (12 - 17 1/2").
Available Shanks: IR QL 120.
-
The Super Dominator 800 is a general purpose hammer suitable for a wide range of air pressures. The Dominator 800 is a low to mid range air volume hammer. The one piece top-adaptor with N.R.V. (Non-Return-Valve) makes it easy to maintain and service the hammer. The Dominator 800 unique’s air distributor finger is integral with the top-adaptor and reduces requirements for shimming. The Dominator 800 has no liner which increases the piston blow energy and reduces parts required. This hammer is suitable for use with overburden systems.
Dominator 800 is available in three different shank types (see below).
Suitable for operation at air pressures of 100 - 435 psi (7 - 30 bar).
Drilling diameters of 200 - 311 mm (7 7/8 - 14 1/4").
Available Shanks:
Halco Mach 80
IR DHD 380
Sandvik Mission A63-15/SD8 -
The Dominator 10 is designed for small diameter drilling operations and its superior drilling performance makes it at least 50% faster than its nearest competitor.The valveless design of the Dominator 10 provides high performance at both low and high pressures. The Dominator 10 has a strong robust design withstands heavy duty applications. A N.R.V. (Non-Return-Valve) is fitted into the Dominator 10 to prevent flooding where ground water is present.
Suitable for operation at air pressures of 100 - 250 psi (7 - 17 bar).
Drilling diameters of 55 - 64 mm (2 1/8 - 2 1/2").
Available Shanks: Halco Dominator 1 -
Hammer Dominator 850 Part Number 600245 600400 Shank QL80 QL80 Top Thread 4 1/2" API Reg Pin 4 1/2" API Reg Pin Hammer Flat Size 125mm (4.921") 149mm (5.866") Weight 210Kg 210Kg Outside Diameter 192mm (7.559") 192mm (7.559") Make Up Length 1281mm (50.433") 1281mm (50.433") Recommended
Maximum Thrust2000Kg (4400 lbs) 2000Kg (4400 lbs) -
Dominator 375 hammer gives up to 25% increase in performance compared to Dominator 350 and Dart 350. This exceptional hammer is simple, robust and has a high penetration rate. The Dominator 375 has an integral N.R.V. (Non-Return-Valve) with an adjustable air bleed system to adjust air volume, this hammer has a liner and solid piston design.
This hammer has few internal parts which makes on site servicing easy with minimum tools needed. The MD 3.5 shank drill bit can be fitted for improved service life and heavy duty applications.
Suitable for operation at air pressures of 100 - 350 psi (7 - 24 bar).
Drilling diameters of 95 mm - 115 mm (3 1/2 - 4 1/8").
Available Shanks: IR DHD 3.5, MD 3.5.
-
Dominator 375 hammer gives up to 25% increase in performance compared to Dominator 350 and Dart 350. This exceptional hammer is simple, robust and has a high penetration rate. The Dominator 375 has an integral N.R.V. (Non-Return-Valve) with an adjustable air bleed system to adjust air volume, this hammer has a liner and solid piston design.
This hammer has few internal parts which makes on site servicing easy with minimum tools needed. The MD 3.5 shank drill bit can be fitted for improved service life and heavy duty applications.
Suitable for operation at air pressures of 100 - 350 psi (7 - 24 bar).
Drilling diameters of 95 mm - 115 mm (3 1/2 - 4 1/8").
Available Shanks: IR DHD 3.5, MD 3.5.
-
The Super Dominator 450 has been specifically designed for high production drilling in blast-hole applications.
The hammer is robust and has few parts, making it user friendly and reliable. The Super Dominator 450 is fitted with a non-return-valve in top-adaptor for quick and easy inspection and maintenance operations. A fixed air distributor in the top-adaptor body means the Super Dominator 450 requires no shimming which simplifies servicing. The Super Dominator 450 has no liner which increases the piston power output.
The Super Dominator 450 utilizes Halco's all new 12 spline shank which has simplistic robust geometry combined with increased drive contact area. The Super Dominator 450 can be also used with the IR340A/Atlas Copco Cop 44.
Suitable for operation at air pressures of 100 - 350 psi (7 - 24 bar).
Drilling diameters of 110 mm - 127 mm (4 5/16 - 5").
Available Shanks: Halco Super Dominator 450 (NT4), IR 340A/Atlas Copco Cop 44.
-
The Super Dominator 450 has been specifically designed for high production drilling in blast-hole applications.
The hammer is robust and has few parts, making it user friendly and reliable. The Super Dominator 450 is fitted with a non-return-valve in top-adaptor for quick and easy inspection and maintenance operations. A fixed air distributor in the top-adaptor body means the Super Dominator 450 requires no shimming which simplifies servicing. The Super Dominator 450 has no liner which increases the piston power output.
The Super Dominator 450 utilizes Halco's all new 12 spline shank which has simplistic robust geometry combined with increased drive contact area. The Super Dominator 450 can be also used with the IR340A/Atlas Copco Cop 44.
Suitable for operation at air pressures of 100 - 350 psi (7 - 24 bar).
Drilling diameters of 110 mm - 127 mm (4 5/16 - 5").
Available Shanks: Halco Super Dominator 450 (NT4), IR 340A/Atlas Copco Cop 44.
-
-
