| Features | | | |
• Safety features as pressure displays, emergency stop and spill free frame
• FuelXpert™ for optimized fuel consumption
• Oiltronix™ for longer lasting components
• Dual pressure system – variation of output and flow between lower and higher pressure limits
• Ready to operate with a full range of options for all operating conditions
• Fast speed tandem or wagon trailer
• Truck or skid mounted version
• Best for use in all weather conditions -13°F (-25°C) to 122°F (+50°C)
• Cosmos™ |
| Advantages | |
• Higher pressure makes drilling faster
• Higher flow removes the cuttings more efficiently
• Superior productivity is gained by increasing speed
• Operator and enviromental safe
• Optimization of costs by having the best machine pressure, air flow delivery and minimized fuel consumption
|
Model Compressor |
XRVS 830 CD6 |
XRVS 800 CD6 |
XRVS 1100 CD6 |
| Actual free air delivery* | 830 cfm
392 l/sec
23.5 m3/min
| 784 cfm
370 l/sec
22.2 m3/minn | 1059 cfm
500 l/sec
30 m3/min |
| Normal Working Pressure | 246 PSI
17 Bar | 290 PSI
20 Bar | 290 PSI
20 Bar |
| Oil capacity compressor system | 19.8 gal.
75 L | 19.8 gal.
75 L | 19.8 gal.
75 L |
| Content fuel tank (standard) | 142 gal.
538 L | 210 gal.
796 L | 210 gal.
796 L |
| Content fuel tank(tandem) | 142 gal.
538 L | 142 gal.
538 L | 142 gal.
538 L |
| Air outlet valve | 1x2” | 1x2” | 1x2” |
Engine Caterpillar | | |
| Type | C9 ACERT T3 | C9 ACERT T3 | C13 ACERT T3 |
| Output | 300 BHP
224 kW | 300 BHP
224 kW | 426 BHP
318 kW |
| Air outlet valve | 1800 rpm | 1800 rpm | 1600 rpm |
| Air outlet valve | 1300 rpm | 1300 rpm | 1200 rpm |
| *according to ISO1217 ed.3 1996 annex D |
