| Features | | |
• Safety features as pressure displays, emergency stop and spill free frame
• FuelXpert™ for optimized fuel consumption
• Oiltronix™ for longer lasting components
• Ready to drill package with a full range of options for all operating conditions.
• Fast speed tandem or wagon trailer
• Truck or skid mounted version
• Best for use in all weather conditions -13°F (-25°C) to 122°F (+50°C)
• Cosmos™ |
| Advantages | |
• Operator and environmental safe
• Lowest total cost of ownership
• Lowest fuel consumption in class
• Delivers full range of drilling and hole options
• Rugged frame built to last
• Best fuel efficiency for complete working shift
|
Essential Data |
XRVS 700 CD6 |
XRVS 1000 CD6 |
| Actual free air delivery* | 695 cfm
328 l/sec
19.7 m3/min
| 974 cfm
460 l/sec
27.6 m3/min |
| Normal Working Pressure | 362 PSI
25 Bar | 362 PSI
25 Bar |
| Oil capacity compressor system | 20 gal.
75 L | 20 gal.
75 L |
| Content fuel tank (standard) | 142 gal.
538 L | 210 gal.
796 L |
| Content fuel tank(tandem) | 142 gal.
538 L | 142 gal.
538 L |
| Air outlet valve | 1x2 1/2” | 1x2 1/2” |
Engine Caterpillar | | |
| Type | C9 ACERT T3 | C13 ACERT T3 |
| Output | 300 BHP
224 kW | 426 BHP
318 kW |
| Air outlet valve | 1800 rpm | 1600 rpm |
| Air outlet valve | 1300 rpm | 1200 rpm |
| |
