Portable Air Compressor 375 HH |
375 CFM AT 200 PSIG - 177 L/S AT 14 BAR |
• ROTARY SCREW COMPRESSOR • REMOVABLE MODULAR CANOPY • ADJUSTABLE HEIGHT HITCH • E-Z LUBE AXLE • LARGE TOOL BOX COMPARTMENT • CURBSIDE INSTRUMENT PANEL • SSAM-SHUTDOWN SYSTEM AND ANNUNCIATION MODULE • BATTERY DISCONNECT SWITCH • IDLE WARM-UP SWITCH • ROCKER TYPE START SWITCH • EMERCENCY STOP
| • PROTECTIVE SHUTDOWN SWITCHES • FUEL/WATER SEPARATOR • THREE STAGE AIR FILTERS • 0 TO 100% CAPACITY CONTROL • PNEUMATIC INLET VALVE • AWF COMPRESSOR FLUID • DURABLE POWDER COAT FINISH • WIDE TRACK • GALVANNEAL SHEET METAL • RECESSED TAIL LIGHTS • REAR BUMPER
|
DESIGNED FOR TOTAL ACCESSIBILITY AND RELIABILITY |
Rotary Screw Compressor | |
Ample Service Doors Large service doors provide access to fuel tank, engine, compressor, air filters and tool compartment. Rear service panel provide access to side-byside compressor fluid cooler, engine air cooler and engine radiator. Serviceable components within easy reach. Routine maintenance is simplified. Reduced downtime and service cost. Service doors feature non-rusting hinges and stainless steel T-type door retainers. Multi-Piece Canopy Modular design reduces replacement costs. Easily removed as one assembly for major service. Exposed, single point lifting bail. 0 to 100% Capacity Control Pneumatic inlet valve and unloaded starting. Highway Towable Running Gear 3" square drawbar. Adjustable height hitch (15", 17", 19"). Quick-change hitch. Screw jack with pad. Transport security chains. E-Z lube axle lubrication. Heavy duty leaf spring suspension. Curbside Instrument Panel Hinged, padlockable cover. Mechanical air pressure gauge, Powerview (John Deere) Hourmeter (Caterpillar). | Rocker type engine start switch. Idle warm-up valve.High/low pressure selecor valve allows dual pressure capability without making mechanical adjustments.SSAM–Shutdown System & Annunciation Module Shutdown with annunciator light for high compressor temperature, high engine coolant temperature, low engine oil pressure, engine underspeed and low fuel shutdown. Three-Stage Dry Type Air Filters Separate filters for engine and compressor. Durable, Baked-On Powder Coat Finish AWF Compressor Fluid All-weather, all-climate fluid. Tier 3 Emission Compliant Engine Air End Warranty 2 year standard warranty. 5 year or 10,000 hour warranty when continuously serviced at the recommended intervals with Sullair AWF Compressor Fluid and filters. Quiet Operation Meets US EPA Sound requirements of 76 dBA @ 7 meters. This product is manufactured to the highest quality standards in an ISO 9001 certified quality system.. |
SULLAIR’S OPTIONS ALLOW YOU TO CUSTOMIZE THE COMPRESSOR TO MEET YOUR SPECIFIC REQUIREMENTS WITHOUT PAYING FOR ITEMS YOU DO NOT NEED. |
Filtration for instrument quality air. Aftercooler. Special paint. Hose reels, single and dual.Spark arrestor. Cold weather starting aid. Fuel level gauge. Brakes (Recommended where required by law.) | Mechanical parking brakes. Ball hitch. Retractable pneumatic swivel third wheel. Air filter maintenance indicators.Block heater. Ether starting aid (John Deere). |
