Drill Rods
RP640 SERIES R WIRELINE DRILL RODS
| Part No | Description | Length | ID mm | ID in | OD mm | OD in | Weight kg | Weight lb |
|---|---|---|---|---|---|---|---|---|
| BG00917369 | Drill Rod, NR | 1.5 m | 60.3 | 2.37 | 69.9 | 2.75 | 11.60 | 25.40 |
| BG00917237 | Drill Rod, NR | 3.0 m | 60.3 | 2.37 | 69.9 | 2.75 | 23.10 | 50.93 |
| BG01080373 | Drill Rod, HR | 1.5 m | 77.8 | 3.06 | 88.9 | 3.50 | 17.10 | 37.70 |
| BG01080166 | Drill Rod, HR | 3.0 m | 77.8 | 3.06 | 88.9 | 3.50 | 34.20 | 75.40 |
| Request Quote | ||||||||
RP622 SERIES WIRELINE DRILL RODS
| The RP622 series of drill rod features the industry standard modified ACME thread on the box and pin ends with the appropriate stand-off gap to ensure a tight seal. | |||||||||
| Metric length rods | |||||||||
| PART LIST | |||||||||
| Part Number | Description | Length | ID | OD | Weight | ||||
| mm | in | mm | in | kg | lb | ||||
| BB00000167 | Drill Rod, B | 0,6 m | 46,0 | 1,81 | 55,6 | 2,19 | 3,58 | 7,89 | |
| BB00000035 | Drill Rod, B | 1,5 m | 46,1 | 1,81 | 55,6 | 2,19 | 8,95 | 14,65 | |
| BB00000037 | Drill Rod, B | 3,0 m | 46,1 | 1,81 | 55,6 | 2,19 | 17,9 | 39,46 | |
| BB00000168 | Drill Rod, N | 0,6 m | 60,3 | 2,38 | 69,9 | 2,75 | 4,58 | 10,10 | |
| BB00000038 | Drill Rod, N | 1,5 m | 60,3 | 2,38 | 69,9 | 2,75 | 11,45 | 25,25 | |
| BB00000039 | Drill Rod, N | 3,0 m | 60,3 | 2,38 | 69,9 | 2,75 | 22,90 | 50,49 | |
| BB00000169 | Drill Rod, H | 0,6 m | 77,8 | 3,06 | 88,9 | 3,50 | 7,16 | 15,08 | |
| BB00000040 | Drill Rod, H | 1,5 m | 77,8 | 3,06 | 88,9 | 3,50 | 17,93 | 37,70 | |
| BB00000041 | Drill Rod, H | 3,0 m | 77,8 | 3,06 | 88,9 | 3,50 | 34,20 | 75,40 | |
| Imperial length rods | |||||||||
| Part Number | Description | Length | ID | OD | Weight | ||||
| mm | in | mm | in | kg | lb | ||||
| BB00000044 | Drill Rod, B | 5 ft | 46,1 | 1,81 | 55,6 | 2,19 | 9,53 | 21,00 | |
| BB00000045 | Drill Rod, B | 10 ft | 46,1 | 1,81 | 55,6 | 2,19 | 19,05 | 42,00 | |
| BB00000046 | Drill Rod, N | 5 ft | 60,3 | 2,38 | 69,9 | 2,75 | 12,25 | 27,00 | |
| BB00000047 | Drill Rod, N | 10 ft | 60,3 | 2,38 | 69,9 | 2,75 | 24,04 | 53,00 | |
| BB00000048 | Drill Rod, H | 5 ft | 77,8 | 3,06 | 88,9 | 3,50 | 18,14 | 40,00 | |
| BB00000050 | Drill Rod, H | 10 ft | 77,8 | 3,06 | 88,9 | 3,50 | 35,83 | 79,00 | |
| âWTâ Thread | |||||||||
| Part Number | Description | Length | ID | OD | Weight | ||||
| mm | mm | kg | |||||||
| BB00000238 | Drill Rod, P | 1.5 m | 101.6 | 114.3 | 26.79 | ||||
| BB00000239 | Drill Rod, P | 3.0 m | 101.6 | 114.3 | 52.56 | ||||
| *BB00000174 | Drill Rod, S (Casing, PWT) | 0.6 m | 126.6 | 139.7 | 12.86 | ||||
| *BB00000122 | Drill Rod, S (Casing, PWT) | 1.5 m | 126.6 | 139.7 | 32.15 | ||||
| *BB00000175 | Drill Rod, S (Casing, PWT) | 3.0 m | 126.6 | 139.7 | 64.30 | ||||
* not heat treated NOTE: âPâ 0.6 m heat treated drill rod is available as special order only.
| |||||||||
RP623 SERIES WIRELINE DRILL RODS
| The RP623 series of drill rod features a robust, modified square profile thread on the box and pin ends commonly referred to in the industry as "T". | |||||||||
| Metric length rods | |||||||||
| PART LIST | |||||||||
| Part Number | Description | Length | ID | OD | Weight | ||||
| mm | in | mm | in | kg | lb | ||||
| BB00000123 | Drill Rod, BT | 1,5 m | 46,1 | 1,81 | 55,6 | 2,19 | 8,95 | 14,65 | |
| BB00000052 | Drill Rod, BT | 3,0 m | 46,1 | 1,81 | 55,6 | 2,19 | 17,9 | 39,46 | |
| BB00000053 | Drill Rod, NT | 1,5 m | 60,3 | 2,38 | 69,9 | 2,75 | 11,45 | 25,25 | |
| BB00000054 | Drill Rod, NT | 3,0 m | 60,3 | 2,38 | 69,9 | 2,75 | 22,90 | 50,49 | |
| BB00000055 | Drill Rod, HT | 1,5 m | 77,8 | 3,06 | 88,9 | 3,50 | 17,93 | 37,70 | |
| BB00000056 | Drill Rod, HT | 3,0 m | 77,8 | 3,06 | 88,9 | 3,50 | 34,20 | 75,40 | |
| Imperial length rods | |||||||||
| Part Number | Description | Length | ID | OD | Weight | ||||
| mm | in | mm | in | kg | lb | ||||
| BB00000057 | Drill Rod, BT | 5 ft | 46,1 | 1,81 | 55,6 | 2,19 | 9,53 | 21,00 | |
| BB00000058 | Drill Rod, BT | 10 ft | 46,1 | 1,81 | 55,6 | 2,19 | 19,05 | 42,00 | |
| BB00000059 | Drill Rod, NT | 5 ft | 60,3 | 2,38 | 69,9 | 2,75 | 12,25 | 27,00 | |
| BB00000060 | Drill Rod, NT | 10 ft | 60,3 | 2,38 | 69,9 | 2,75 | 24,04 | 53,00 | |
| BB00000061 | Drill Rod, HT | 5 ft | 77,8 | 3,06 | 88,9 | 3,50 | 18,14 | 40,00 | |
| BB00000062 | Drill Rod, HT | 10 ft | 77,8 | 3,06 | 88,9 | 3,50 | 35,83 | 79,00 | |
 | |||||||||
 |  |  | |||||||
