Water SWIVEL Model 45JSS
Description

Details

For Core Drilling and High-Speed Drilling
These swivel is designed for high drilling speeds. The bearings are flush ground, high angular contact, giving exceptional thrust and radial stability. They are sealed in the housing and are grease lubricated. The packing is non-adjustable, Chevron V-Type, selected for high-speed applications.

PART LIST FOR 45JSS SWIVEL
Part No
Name of Part
Number required
Weight lbs
Spare for one
year Service
N45SS01
Gooseneck
1
2
-
N45SS-02
Lock Nut
1
0
-
N45SS03
Packing Set
1
0
6
N45JSS03B
Wear Sleeve
1
0
2
N45JSS04
Packing Box
1
0
2
N45JSS05
Spindle
1
2
1
N45JSS07
Housing Beal
1
-
1
N45JSS08
Bearing Housing
1
5
-
N45JSS09A
Bearing Lock Nut
1
0
1
N45JSS09B
Bearing Lock Washer
1
0
1
N10XV12
Bearing
3
4
-
N26WG233
0-Ring
1
0
6
