| Pump Model | AL0918 | | |
| Configuration | Horizontal Triplex Piston | Piston Diameter | 2.25 in | 57.2 mm |
| Number of Pistons | 3 | Displacernent/REV | 0.0323 Gallon | 0.122 Liters |
| Stroke Length | 2.25 Inches (57.2 mm) | Maximum Pressure | 700 PSI | 49.2 kg/cm2 |
| Frame Load Rating | 2800 lbs. (1,270 kg) | |
| Pump Weight | 200 lbs. (90.7 kg) | Pump Capacity Input Speed (RPM) |
| Direction of Rotation | Top of Shaft away from head | 350 RPM | 11.3 gpm | 43 Lpm |
| Internal Gear Rotation | 3.6:1 | 625 RPM | 20.2 gpm | 76 Lpm |
| Intermittent Duty Speed Rating | 890 RPM (Jackshaft) | 700 RPM | 22.6 gpm | 86 Lpm |
| Continuous Duty Speed Rating | 750 RPM (Jackshaft) | 750 RPM | 24.2 gpm | 92 Lpm |
| Ball Valve Max Speed Rating | 625 RPM | 890 RPM | 28.7 gpm | 109 Lpm |
| Minimum Speed | 360 RPM | | |
| Mechanical Efficiency | 85% | | |
| Lubrication System | Splash, Gravity Return | | |
| Lube Oil Capacity | 2.25 Quarts | | |
| Lube Oil Type | SAE 30 | | |
| Maximum Fluid Temperature | 140 °F (250 °F Capability) | | |
| Minimum Fluid Temperature | 0 °F (-20 °F Capability) | | |
| Standard Suction Size | 1.50 Inch NPT (38.1 mm) | | |
| Standard Discharge Size | 1.00 Inch NPT (25.4 mm) | | |
| Fluid End Material | Cast Iron | | |
| Valve Type | Disc Valve / Ball Valve | | |
| Hydraulic Motor Mount | SAE C - 4 Bolt with 1.25"-14T | | |
