Pump Model | AW1122BCD | Piston Diameter | 2.75 in | 69.9 mm |
Configuration | Horizontal Triplex Piston | Displacernent/REV | 0.0589 gallon | 0.223 Liters |
Number of Pistons | 3 | Maximum Pressure | 1,000 PSI | 70.3 kg/cm2 |
Stroke Length | 2.75 Inches (69.9 mm) | |
Piston Load | 5940 lbs. (2,697 kg) | Pump Capacity Input Speed (RPM) |
Pump Weight | 460 lbs. (209 kg) | 350 RPM | 20.6 gpm | 78 Lpm |
Direction of Rotation | Top of Shaft away from head | 500 RPM | 29.5 gpm | 112 Lpm |
Internal Gear Rotation | 3.6:1 | 635 RPM | 37.4 gpm | 142 Lpm |
Intermittent Duty Speed Rating | 900 RPM (Jackshaft) | 750 RPM | 44.2 gpm | 167 Lpm |
Continuous Duty Speed Rating | 750 RPM (Jackshaft) | 900 RPM | 53 gpm | 201 Lpm |
Ball Valve Max Speed Rating | 635 RPM (Jackshaft) | | |
Minimum Speed | 360 RPM | | |
Mechanical Efficiency | 85% | | |
Lubrication System | Splash, Gravity Return | | |
Lube Oil Capacity | 1 Gallon | | |
Lube Oil Type | SAE 30 | | |
Maximum Fluid Temperature | 140°F (250° Capability) | | |
Minimum Fluid Temperature | 0°F (-20° Capability) | | |
Standard Suction Size | 2.00 Inch NPT (50.8 mm) | | |
Standard Discharge Size | 1.25 Inch NPT (38.1 mm) | | |
Fluid End Material | Ductile Iron | | |
Valve Type | Ball Valves | | |
