Rineer model M125H4

Rineer model M125H4
Features of the 125 Hi-Pressure Series 4-Port Motor
125 Hi-Pressure Series Motor - 4500 PSI*
Description

Details

  • A variety of fixed displacement motors
    ranging from 60 in3 to 250 in3.
  • Same starting, stall, and low speed torque.
  • Speed to 350 RPM continuous.
  • Up to 400 HP continuous*.
  • 10" diameter x 19" long - single stack - 330 lbs.
  • 10" diameter x 22" long - double stack - 390 lbs.
  • 10" diameter x 27" long - 4-port - 450 lbs.
  • Two speed operation with some external valving
    (4-port version)
