Funk 12700 HMD Transmission |
Ratings | | | Gear ratio (helical gears, sliding collar shift) |
Input power (max) | 104 kW (140 hp) | | Low | 2nd | 3rd | High |
Input torque (max) | 407 Nm (300 lb-ft) | | 6.27:1 | 3.12:1 | 1.75:1 | 1:1 |
Input no load speed (max) | 2500 rpm | | | | | |
General data | | | Splines |
Motor adapters | SAE C and D | | Input | SAE 14-tooth 12/24 DP |
Approximate dry weight | 88 kg (194 lb) | | | SAE 13-tooth 8/16 DP |
Oil | | | Parking brake | Drum-type |
Capacity | 88 kg (194 lb) | | Output fittings |
Type | MIL-L-2105-C or | | Adapts to Spicer series 1500 and 1600 |
| API classification GL-5 | | Mechanics 7C U-joint flange yoke |
Features and benefits |
Controlled ground speed at full engine power |
Available to use with applications up to 104 kW (140 hp) |
2500 rpm max input, no load speed. |
Multiple gear ratios in four-speed versions |
Covers low-speed working range through high-gear travel speeds |
Wide speed variance in each gear range |
Selection of SAE hydraulic input motor mountings |
SAE C and D mounts to utilize input hydraulics to best fit the application |
