Product number | 52292273 |
Outside diameter, mm (in) | 130 (5.13) |
Length without bit, mm (in) | 1152 (45.4) |
Length with bit extended, mm (in) | 1276 (50.2) |
Length with bit retracted, mm (in) | 1232 (48.5) |
Weight without bit, kgs (lb) | 72 (158) |
Spanner flat on top sub, mm (in) | 102 (4) |
Minimum bit size, mm (in) | 140 (5 ½) |
Maximum bit size, mm (in) | 152 (6) |
Cylinder bore, mm (in) | 113,7 (4.48) |
Piston weight, kgs (lb) | 17 (38) |
Stroke length, mm (in) | 64 (2.5) |
Working pressure, bar (psi) | 10-35 (145–500) |
Make up torque, Nm (ft-lb) | 6800 (5000) |
Thread connection | 4 1/2 inch Remet BOX |
