Portable Air Compressor 185

Clam Shell Canopy:
Canopy opens fully with gas assist springs.
Serviceable components are within easy
reach, routine maintenance is simplified.
Corrosion Resistant Enclosure:
Galvanneal sheet metal with composite
end caps and fenders.
Stainless steel hinges and latches, plated
fittings and hardware.
Aluminum instrument panel door.
Durable, Baked-on Powder Coat Finish
Highway Towable Running Gear:
Independent rubber torsion suspension.
Axle offers convenient wheel bearing
lubrication through zerk fittings.
3” square drawbar.
Screw jack with pad.
Adjustable height hitch.
Transport security chains.
Recessed tail lights.
Rear bumper.
Environmental Features:
Sealed crankcase ventilation system.*
500 hour engine oil change.*
1200 hour compressor lube change.
Curbside Instrument Panel
Hinged, padlockable cover.
Mechanical air pressure gauge and
hourmeter.
Rocker type engine start switch, with
emergency stop.
Idle warm-up valve.
Glow plug starting aid.

SSAM–Shutdown System &
Annunciation Module
Shutdown with annunciator light for high
compressor temperature, high engine
coolant temperature, low engine oil
pressure and engine underspeed.
Capacity Control System
Pneumatic inlet valve and unloaded starting.
Color coded control lines.
Heated controls to prevent freezing.
Two-Stage Dry Type Air Filters
Separate filters for engine and compressor.
Dual Fuel Filtration System
Primary fuel / water separator with
transparent bowl and water drain.
Final filter with drain.

AWF Compressor Fluid
All-weather, all-climate fluid.
Air End Warranty
5 year or 10,000 hour warranty when
continuously serviced at the
recommended intervals with Sullair
AWF Compressor Fluid and filters.
2 year standard warranty.
Quiet Operation
Meets US EPA Sound requirements of
76dBA @ 7 meters.
This product is manufactured
to the highest quality
standards in an ISO 9001
certified quality system.
