DTH HAMMER DS10

DTH HAMMER DS10
The BR1 and BR2 are both valved type DTH hammers designed for high performance at low operating air pressures.
Simplicity of design, ease of service and low air consumption are all factors which combine to make these hammers robust and reliable drilling tools. Both hammers are available as standard with box backheads, RD40 for the BR1 and RD50 for the BR2. However alternative backhead options are available on request.
The BR1 and BR2 hammers both incorporate a positive fitting check valve to guard against the ingress of ground water debris when the air is shut off.

BUTTON BITS

Bit Dia. BR1 BR2
60 mm BBS011FF060   -
64 mm BBS011FF064   -
70 mm - BBS012FF070
76 mm - BBS012FF076
80 mm - BBS012FF080
Description

Details

Bulroc Valved Type DTH Hammer BR1 (60-64mm) BR2 (70-80mm) dia hole

HAMMER SPECIFICATIONS
BR1 BR2
  English Metric English Metric
Weight (less bit) 17.6Ibs 8kgs 28.6Ibs 13kgs
Length (less bit) 27.9" 709m 33" 838mm
Outside dia. 2" 51mm 2.44" 62mm
Piston weight 2.2Ibs 1kg 4.0Ibs 1.8kg
Stroke 3" 76mm 4.0” 101mm

AIR CONSUMPTION
PSI Bar Hammer CFM M3/min
100 7 BR1 / BR2 17.79 / 26.65 0.50 / 0.75
150 10.3 BR1 / BR2 32.69 / 48.96 0.93 / 1.39
200 13.8 BR1 / BR2 50.32 / 75.38 1.43 / 2.13
250 17.2 BR1 / BR2 70.33 / 105.35 1.99 / 2.98
