DTH HAMMER DS1000
The DS1000 DTH hammer has faster penetration, longer life, and less down time due to down hole failures.
- DIFFERENT SHANK DESIGN
- SUPERIOR TECHNOLOGY
- DELIVERS MORE ENERGY PER BLOW
- HARDENED PISTON FOR EXTENDED LIFE
Working pressure: 150 - 250
Application Bit: 9.50"- 14"
Feed Force(lbs.): 3500 - 7,000
  • DTH Hammers Bits

* Required Fields

Description

Details

DTH Hammer DS1000

SPECIFICATIONS DS-1000-N (N100) DS-1000-S (SD10)
Weight (less bit) 772 lbs 772 lbs
Length (less bit) 62" 59.6"
Outside dia. 8.86" 8.86"
Piston weight 117 117
TOP SUB 6.58" API PIN 6.58" API PIN
Stroke 3.90" 3.90"
Piston dia. 6.85" 6.85"

AIR CONSUMPTION at Different Working Pressures
150 psi (scfm) 690
200 psi (scfm) 980
250psi (scfm) 1290
