DTH HAMMER DS150

More Views

DTH HAMMER DS150
The DS-150 DTH hammer has faster penetration, longer life, and less down time due to down hole failures.
Working pressure: 150 - 250
Application Bit: 17 - 20
Feed Force(lbs.): 6,000 - 10,000
- SD15 SHANK DESIGN
- SUPERIOR TECHNOLOGY
- DELIVERS MORE ENERGY PER BLOW
- HARDENED PISTON FOR EXTENDED LIFE
  • DTH Hammers Bits
Description

Details

DTH Hammer DS150 (SD15)

DS150 DTH HAMMER SPECIFICATIONS
Weight (less bit) 2769 lbs
Length (less bit) 72"
Outside dia. 14.8"
Piston weight 533
Stroke 5"
Piston Dia 11.22"

AIR CONSUMPTION at Different Working Pressures
100 psi (scfm) 1050
150 psi (scfm) 1350
200 psi (scfm) 1800
250 psi (scfm) 2500
