DTH HAMMER DS240

More Views

DTH HAMMER DS240
The DS-240 DTH hammer has faster penetration, longer life, and less down time due to down hole failures.
Working pressure: 100 - 200
Application Bit: 22 - 32
Feed Force(lbs.): 8,000 - 20,000
- N240 SHANK DESIGN
- SUPERIOR TECHNOLOGY
- DELIVERS MORE ENERGY PER BLOW
- HARDENED PISTON FOR EXTENDED LIFE
  • DTH Hammers Bits
Description

Details

DTH Hammer DS240 (N240)

DS240 DTH HAMMER SPECIFICATIONS
Weight (less bit) 5586 lbs
Length (less bit) 80"
Outside dia. 20.63"
Piston weight 899
Stroke 5.90"
Piston Dia 15.55"

AIR CONSUMPTION at Different Working Pressures
100 psi (scfm) 3000
150 psi (scfm) 3600
200 psi (scfm) 4350
