DTH HAMMER DS30
The DS-30 DTH hammer has faster penetration, longer life, and less down time due to down hole failures.
Working pressure: 150 - 350
Application Bit: 3.5" - 4"
Feed Force(lbs.): 500 - 1,900
- IR3.5/XL3 SHANK DESIGN
- SUPERIOR TECHNOLOGY
- DELIVERS MORE ENERGY PER BLOW
- HARDENED PISTON FOR EXTENDED LIFE
  • DTH Hammers Bits
Description

Details

DTH Hammer DS30-I(IR3.5/XL3)

DS30 DTH HAMMER SPECIFICATIONS
Weight (less bit) 53 lbs
Length (less bit) 34.25"
Outside dia. 3.35"
Piston weight 8.4
Stroke 3.00"
Piston Dia 2.40"
Top Sub 2.38" API Pin

AIR CONSUMPTION at Different Working Pressures
150 psi (scfm) 215
200 psi (scfm) 275
250 psi (scfm) 350
350 psi (scfm) 480

ENGLISH HAMMERS BROCHURES

SPANISH HAMMERS BROCHURES

DS30-I(IR3.5/XL3) DS30-I(IR3.5/XL3)
