DTH HAMMER DS50

More Views

DTH HAMMER DS50
The DS50 DTH hammer has faster penetration, longer life, and less down time due to down hole failures.
- DIFFERENT SHANK DESIGN
- SUPERIOR TECHNOLOGY
- DELIVERS MORE ENERGY PER BLOW
- HARDENED PISTON FOR EXTENDED LIFE
Working pressure: 150 - 350
Application Bit: 5"- 5 7/8"
Feed Force(lbs.): 1000 - 3,700
  • DTH Hammers Bits

* Required Fields

Description

Details

DTH Hammer DS50

SPECIFICATIONS DS50-I(IR 350R) DS50-Q(QL50) DS50-S(SD5)
Weight (less bit) 137 lbs 137 lbs 137 lbs
Length (less bit) 47.5" 46.7" 46.7"
Outside dia. 4.76" 4.76" 4.76"
Piston weight 25 25 25
TOP SUB 3.5” API PIN 3.5” API PIN 3.5” API PIN
Stroke 4" 4" 4

AIR CONSUMPTION at Different Working Pressures
150 psi (scfm) 310
250 psi (scfm) 555
350psi (scfm) 720
