DTH HAMMER DS60

The DS 60 DTH hammer has faster penetration, longer life, and less down time due to down hole failures.
- DIFFERENT SHANK DESIGN
- SUPERIOR TECHNOLOGY
- DELIVERS MORE ENERGY PER BLOW
- HARDENED PISTON FOR EXTENDED LIFE
Working pressure: 150 - 350
Application Bit: 5.87"- 6.75"
Feed Force(lbs.): 1300 - 4,500

Ask For Price

*Hammer Model

To add all hammer components to quote click - select all

* Required Fields

Qty:

| Add to Compare

Description

Details

DTH Hammer DS60

SPECIFICATIONS	DS60-I(IR DHD360)	DS60-Q(QL60)	DS60-S(SD6)
Weight (less bit)	198 lbs	198 lbs	209 lbs
Length (less bit)	47.9"	45.7"	48.5"
Outside dia.	5.59"	5.59"	5.59"
Piston weight	41.6	41.6	41.8
TOP SUB	3.5” API PIN	3.5” API PIN	3.5” API PIN
Stroke	4"	4"	4
Piston dia.	4.43"	4.43"	4.43"

AIR CONSUMPTION at Different Working Pressures
150 psi (scfm)	435
250 psi (scfm)	665
350psi (scfm)	900

RELATED BITS

Pic	Product Name	Qty
	DTH Bits SD6, QL6, IR360, MACH60, COP62 Shank
