DTH Bit 4-3/4"

DTH Bit 4-3/4"
We offer a diverse line of Down The Hole bits that range from 2" -42" in diameter for use in most all leading hammer shanks. The DTH bits have a wide variety of face configurations as there are many different rock formations and drilling environments.

* Required Fields

Description

Details

DS DTH BIT FACE DESIGNS

Head Designs - CC KRUSHER BIT CC KRUSHER BIT
The CC KRUSHER bit combines three distinctly different face angles, while providing the best features of the Concave and the Convex designs. Specifically, the CC Krusher offers both straight-hole drilling and excellent penetration rates.
Formation: Medium to Hard
Hole Straightness: Average
Penetration Rate: Excellent
FLAT FACE BIT FLAT FACE BIT
The FLAT FACE bit is simple and robust face design, best suited for very hard formations. It can also be used in soft formations where vertical deviation is not a priority.
Formation: Good
Hole Straightness: Fair
Penetration Rate: Excellent
CONCAVE BIT CONCAVE BIT
The CONCAVE bit is suited for most drilling conditions, as this design holds a very straight hole due to the tapered recess in the face of the bit. This recess or so-called "dish" causes a slight coring action, which helps keep the hole straight, while providing for excellent penetration and good air flushing of the hole.
Formation: Medium to Hard
Hole Straightness: Very Good
Penetration Rate: Fair
DROP CENTER BIT DROP CENTER BIT
The DROP CENTER bit, as it name suggests, features a recess in the impact face. This recess provides a coring action, which helps keep the hole straight.
Formation: Sloping and Broke, Medium to Hard
Hole Straightness: Good
Penetration Rate: Average
CONVEX BIT CONVEX BIT
The CONVEX bit is suited for very hard and abrasive formations as it incorporates two different gage rows leading up to the flat impact face. The inner gage row helps to protect the outer row from excessive wear.
Formation: Medium to Hard
Hole Straightness: Average
Penetration Rate: Excellent
